Earth Ground Testers

• 3- and 4-pole Fall of Potential, earth resistance loop testing
• 4-pole Soil Resistivity testing
• Selective earth ground rod testing using 1 clamp

• 3 and 4-pole fall of potential earth resistance loop testing
• Comes with earth tester; USB cable; 2 clamps; carrying case; earth ground stakes and cable reels
• 4-wire; 3-wire and stakeless testing

• A unique earth ground tester that performs fast, accurate testing with and without stakes
• Tests 3- and 4-pole fall-of-potential, and 4-pole soil resistivity (with stakes)
• Performs selective earth ground rod testing (one clamp + stakes)

• A unique earth ground tester that performs testing with and without stakes
• Tests 3- and 4-pole fall-of-potential, and 4-pole soil resistivity (with stakes)
• Performs selective earth ground rod testing (one clamp + stakes)

• Earth ground ac leakage current measurement
• Heavy-duty clamp jaw stays in alignment and in calibration even in every day, on-the-job industrial environments.
• Identify ac leakage currents without disconnecting the earth ground stake from the grounding system–ideal for system troubleshooting.

• Comes complete with test leads and two auxiliary Earth bars
• AC/DC voltage, resistance, and continuity testing
• Auto power off

G9305 series can perform precise 3-wire and simple 2-wire earth resistance measurement for power and electrical systems, lightning protection equipment, and ground system of all electrical equipment.

• Autoranging ground resistance measurements from 0.025? to 1500? with 0.002? resolution
• Programmable high/low alarm
• Large 23mm jaw size for large ground rods

• Earth resistance measurements up to 2000?
• 2, 3 and 4 wire testing procedures
• Also measures AC earth voltage

• Functions: earth resistance testing; earth voltage testing
• Data Hold function
• Reinforced insulation protection

• UT523 Series Earth Resistance Soil Resistivity Tester is specially designed and manufactured for measuring earth resistance, soil resistivity, earth voltage, AC voltage.
• Adopting the latest digital and micro-processing technology, precise 4-pole, 3-pole and simple 2-pole method for earth resistance measurement.
• Importing FFT and AFC technology, with a unique function of anti-interference capability and the ability to adapt to the environment.

• Cable reel connects to Fluke 1621, 1623, and 1625 Ground Testers for measuring the capacity of the individual ground system or electrode to remove power from the site
• Ends with banana plug and connector to attach ground tester to Fluke ground stakes
• Hand crank) on top of the rewind cable reel after use

• Ground/Earth Cable Reel 25 m (81.25 ft)
• Terminates with banana plug and connector to attach earth ground tester to earth stakes
• Both plug and connector can be inserted into top of reel to avoid unspooling of cable

• Ground/Earth Cable Reel 25 m (81.25 ft)
• Terminates with banana plug and connector to attach earth ground tester to earth stakes
• Both plug and connector can be inserted into top of reel to avoid unspooling of cable

• Ground/Earth Cable Reel 50 m (162.5 ft)
• Terminates with banana plug and connector to attach earth ground tester to earth stakes
• Both plug and connector can be inserted into top of reel to avoid unspooling of cable

• IP56 rated for outdoor use
• 3- and 4-pole Fall-of-Potential, earth resistance loop testing
• 4-pole Soil Resistivity testing

• This is a handy measuring instrument, which allows fast and easy determination of the earth resistance. The earth tester / earth resistance meter determines the earth resistance with three-wire technology in three measuring ranges up to 2000 Ω.
• This grounding measuring device offers a normal resistance measurement up to 200 kΩ, the measurement of the ground voltage, and a voltage measurement for DC and AC voltage.
• The battery voltage is displayed next to the measured value in the large LCD display with background lighting which helps the measuring technician to recognize the charging status of the batteries directly from the earthing device.
• In addition to the earthing device and the necessary measuring cables, the earth spikes are also included in the delivery. The set is completed by a carrying case, in which all the accessories of the earthing device can be found and can therefore be taken everywhere.
