Specifications | Range | UT33C+ |
DC voltage (V) | 200mV/2V/20V/200V/600V | ±(0.5%+2) |
AC voltage (V) | 200V/600V | ±(1.2%+3) |
DC current (A) | 2000μA/20mA/200mA/10A | ±(1%+2) |
Resistance (Ω) | 200Ω/2kΩ/20kΩ
/200kΩ/20MΩ | ±(0.8%+2) |
Temperature | -40℃~1000℃ | ±(1%+4) |
-40℉~1832℉ | ±(1.5%+5) |
Features |
Display count | | 2000 |
Auto power off/Auto backlight off | | √ |
Diode test/Continuity buzzer | | √ |
2m drop test/ Test probe holder | | √ |
Range selection | | Manual |
General Characteristics |
Power | 1.5V battery (R03) x 2 |
Display | 66mm x 51mm |
Product net weight | Red and grey |
Product color | 206g (batteries included) |
Product size | 134mm x 77mm x 47mm |
Standard accessories | Batteries, test leads, K-type thermocouple |
Standard individual packing | Gift box, English manual |
Standard quantity per carton | 60pcs |
Standard carton measurement | 640mm x 310mm x 350mm |
Standard carton gross weight | 20.6kg |
