Metabo 600765500 KHEV 5-40 BL 220V SDS-Max Rotary Hammer, 8.3 kg, 2-Modes, 1150W

Features

• Maximum drilling progress and high breaking performance thanks to maintenance-free brushless motor and high-performance hammer action
• Long service life thanks to brushless technology and robust aluminium die-cast housings of gear and motor
• Combination hammer with 2 functions: hammer drilling and chiselling
• Metabo VibraTech (MVT) with double dampening: Decoupled handle and impact-absorbing counter-oscillating weight actively reduce vibrations for healthy working also in continuous use.
• Ergonomically shaped, slim gripping area with large speed control trigger for comfortable working
• Easily accessible locking switch for chiselling in continuous mode
• Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised speeds, which remain constant under load
• Optional reduction of speed and impact energy for working in softer materials
• Electronic soft start for precise spot-drilling
• Metabo S-automatic safety clutch: mechanical decoupling of the drive for safe working should the drill stop unexpectedly
• Restart protection: prevents unintentional start-up after power supply interruption
• Overload protection: protects the motor from overheating
• Low-dust chiselling and drilling with external dust extraction ESA max (accessories)

Technical Information

• Power SourceCorded
• Voltage220V
• Motor TypeBrushless
• Max. single blow energy (EPTA)8.7 J
• Maximum impact rate2900 bpm
• Rated input power1150 W
• Drill-Ø concrete with hammer drills40 mm
• Drill-Ø masonry with core bits105 mm
• No-load speed350 \ 500 rpm
• Speed at rated load350 \ 500 rpm
• Bit TypeSDS-max
• Collar diameter64.6 mm
• Weight (without power cable)8.3 kg
• Cable length6 m
• Hammer drilling concrete10.8 m/s²
• Uncertainty of measurement K1.5 m/s²
• Chiseling9.6 m/s²
• Uncertainty of measurement K1.5 m/s²
• Sound pressure level93 dB(A)
• Sound power level (LwA)104 dB(A)
• Uncertainty of measurement K3 dB(A)

Items Included

• Rubber-coated side handle
• Duster
• Plastic carry case
• Drilling depth guide
• Lubricant for tool shank end

Downloads

DatasheetDatasheet
