Megger 1004-448 High Current 200A Lead Set, 5m, 25mm², Adjustable Clamp, CAT IV 600V, for DLRO100 Series
Key Features
?
Question about this product?
Features
- High-current test lead set rated to 200 A for use with Megger DLRO100 series portable 100 A micro-ohmmeters during low resistance measurements on circuit breakers, busbars, and bonding
- 5 m (16.4 ft) cable length provides comfortable reach between the DLRO100 instrument and the test point
- 25 mm² cable cross-section handles sustained high-current injection without excessive voltage drop
- Adjustable clamp terminations accommodate a wide range of conductor and busbar sizes for versatile site use
- CAT IV 600V safety rating to IEC 61010 provides maximum protection in substation and switchgear environments
- Colour-coded red and black for clear polarity identification
- Compatible with DLRO100E, DLRO100EB, DLRO100H, DLRO100HB, DLRO100X, and DLRO100XB
- Megger Part Number: 1004-448
Technical Information
- Current Rating 200 A
- Cable Length 5 m (16.4 ft)
- Cable Cross-Section 25 mm²
- Terminations Adjustable clamp
- Safety Rating CAT IV 600V per IEC 61010
- Compatible Instruments DLRO100 series (DLRO100E, EB, H, HB, X, XB)
- Megger Part Number 1004-448
Items Included
- 1004-448 High Current Lead Set (2 leads, red and black, 5m each, with adjustable clamps)
