Fluke TIX620 30Hz Thermal Imaging Camera, 640x480, 30Hz, -40 to 600 °C
Model # TIX620 30Hz
Key Features
?
Question about this product?
Features
- 640 x 480 resolution infrared camera with advanced focus and a large 5.6 inch high resolution LCD screen
- Features 32x on-camera digital zoom to allow you to get close up shots from a safe distance
- Offers multiple image transfer protocols
- Provides the sharpest ever IR-Fusion® images with an 8 MP visible light camera
Technical Information
- IFOV (spatial resolution)0.85 mRad
- Image resolution (pixel)640 x 480 (307,200 pixels)
- Frame rate30 and 9 Hz
- Field of View32.7° x 24.0°
- Thermal sensitivity (NETD)< 0.04ᵒ C at 30ᵒ C target temp (40 mK)
- Spectral range7.5 µm to 14 µm
- Temperature-40 °C to 600 °C (-40 °F to 1112 °F)
- Laser pointerYes, laser class: 2
- DisplayExtra-large 5.6" color TFT display, 1280 × 800 pixel resolution, Suitable for daylight operation
- Geo-localizationBuilt-in GPS for geo-referencing
- Digital visible light cameraUp to 8 megapixel resolution for image and video recording
- Digital zoomUp to 32x digital zoom
- Operating temperature-25 °C to +55 °C (-13 °F to 131 °F)
- Storing temperature-40 °C to +70 °C (-40 °F to 158 °F)
- HumidityRelative humidity 10 % to 95 %, non-condensing
- ShockOperational: 25G, IEC 68-2-27
- VibrationOperational: 2G, IEC 68-2-6
- Dimension220 x 125 x 155 mm (8.6 x 4.9 x 6.1 inches)
Items Included
- One rechargeable battery
- Battery charger and adapter
- AC adapter
- SD card reader
- Protective lens cap Hand and neck straps Carrying case
- Warranty card and safety instructions
- Calibration certificate
